CES CARBIDE SQUARE END MILLS- Standard- 3F
PRODUCT FEATURES：
- Cutting Materials：Carbon steel, Chrome steel, Alloy steel, Stainless steel, Cast iron.
- Equipment：CNC Vertical Machining Center, Multi-Tasking Machine.
- Applications：Aerospace, Machinery, Mold ＆ Die, Automotive, Motorcycle.
Spec
| Inquiry | Model | Dia.(d) | CL(L1) | OAL(L) | Shank(D) | Flutes(F) | Coating |
|---|---|---|---|---|---|---|---|
| | CESM30200A | 2 | 5 | 50 | 4 | 3 | TIALN |
| | CESM30250A | 2.5 | 6 | 50 | 4 | 3 | TIALN |
| | CESM30300A | 3 | 8 | 50 | 4 | 3 | TIALN |
| | CESM30350A | 3.5 | 9 | 50 | 4 | 3 | TIALN |
| | CESM30400A | 4 | 10 | 50 | 4 | 3 | TIALN |
| | CES30200A | 2 | 5 | 50 | 6 | 3 | TIALN |
| | CES30250A | 2.5 | 6 | 50 | 6 | 3 | TIALN |
| | CES30300A | 3 | 8 | 50 | 6 | 3 | TIALN |
| | CES30350A | 3.5 | 9 | 50 | 6 | 3 | TIALN |
| | CES30400A | 4 | 10 | 50 | 6 | 3 | TIALN |
| | CES30450A | 4.5 | 11 | 50 | 6 | 3 | TIALN |
| | CES30500A | 5 | 13 | 50 | 6 | 3 | TIALN |
| | CES30550A | 5.5 | 14 | 50 | 6 | 3 | TIALN |
| | CES30600A | 6 | 15 | 50 | 6 | 3 | TIALN |
| | CES30650A | 6.5 | 16 | 60 | 8 | 3 | TIALN |
| | CES30700A | 7 | 18 | 60 | 8 | 3 | TIALN |
| | CES30750A | 7.5 | 18 | 60 | 8 | 3 | TIALN |
| | CES30800A | 8 | 20 | 60 | 8 | 3 | TIALN |
| | CES30850A | 8.5 | 20 | 75 | 10 | 3 | TIALN |
| | CES30900A | 9 | 22 | 75 | 10 | 3 | TIALN |
| | CES30950A | 9.5 | 22 | 75 | 10 | 3 | TIALN |
| | CES31000A | 10 | 25 | 75 | 10 | 3 | TIALN |
| | CES31050A | 10.5 | 25 | 75 | 12 | 3 | TIALN |
| | CES31100A | 11 | 25 | 75 | 12 | 3 | TIALN |
| | CES31150A | 11.5 | 25 | 75 | 12 | 3 | TIALN |
| | CES31200A | 12 | 30 | 75 | 12 | 3 | TIALN |
| | CES3130014A | 13 | 30 | 75 | 14 | 3 | TIALN |
| | CES3140014A | 14 | 30 | 75 | 14 | 3 | TIALN |
| | CES31500A | 15 | 35 | 100 | 16 | 3 | TIALN |
| | CES31600A | 16 | 35 | 100 | 16 | 3 | TIALN |
