CECSW CARBIDE V-TYPE DOVETAIL END MILLS- Flat Flute
PRODUCT FEATURES：
- Cutting Tool Design I：The cutting edge is precision-ground to ensure rigidity and accuracy, effectively reducing machining errors and achieving greater precision in keyway processing.
- Cutting Materials：Carbon steel, Chrome steel, Alloy steel, Stainless steel, Cast iron, Aluminum alloy, Copper alloy.
- Equipment：CNC Vertical Machining Center, Multi-Tasking Machine.
- Applications：Aerospace, Machinery, Mold ＆ Die, Automotive, Motorcycle, Mobile Phones, Display Panels.
Spec
| Inquiry | Model | Dia.(d) | δ˚ | CL(L1) | Neck(Nd) | Neck(NL) | OAL(L) | Shank(D) | Flutes(F) | Coating |
|---|---|---|---|---|---|---|---|---|---|---|
| | CECSW060018060A | 6 | 60° | 1.8 | 2.7 | 4 | 60 | 6 | 4 | TIALN |
| | CECSW080024060A | 8 | 60° | 2.4 | 3.6 | 5 | 60 | 8 | 6 | TIALN |
| | CECSW100031060A | 10 | 60° | 3.1 | 4.5 | 6 | 75 | 10 | 6 | TIALN |
| | CECSW120037060A | 12 | 60° | 3.7 | 5.4 | 7 | 75 | 12 | 6 | TIALN |
| | CECSW060028090A | 6 | 90° | 2.8 | 3 | 4 | 60 | 6 | 4 | TIALN |
| | CECSW080038090A | 8 | 90° | 3.8 | 4 | 5 | 60 | 8 | 6 | TIALN |
| | CECSW100048090A | 10 | 90° | 4.8 | 5 | 6 | 75 | 10 | 6 | TIALN |
| | CECSW120058090A | 12 | 90° | 5.8 | 6 | 7 | 75 | 12 | 6 | TIALN |
| | CECSW060018060 | 8 | 60° | 2.4 | 3.6 | 5 | 60 | 8 | 6 | — |
| | CECSW080024060 | 8 | 60° | 2.4 | 3.6 | 5 | 60 | 8 | 6 | — |
| | CECSW100031060 | 10 | 60° | 3.1 | 4.5 | 6 | 75 | 10 | 6 | — |
| | CECSW120037060 | 6 | 90° | 2.8 | 3 | 4 | 60 | 6 | 4 | — |
| | CECSW060028090 | 6 | 90° | 2.8 | 3 | 4 | 60 | 6 | 4 | — |
| | CECSW080038090 | 8 | 90° | 2.8 | 3 | 4 | 60 | 6 | 4 | — |
| | CECSW100048090 | 10 | 90° | 4.8 | 5 | 6 | 75 | 10 | 6 | — |
| | CECSW120058090 | 12 | 90° | 5.8 | 6 | 7 | 75 | 12 | 6 | — |
