METVC ULTRA CARBIDE CORNER RADIUS END MILLS FOR TITANIUM- High Performance- 4F
PRODUCT FEATURES：
- Cutting Tool Design I：Chattering is decreased dramatically with unequal flute spacing ＆ nonequivalent helix angle, increase processing speed and stability.
- Cutting Tool Design II：A rounded tip (R-angle) design effectively distributes cutting stress, reduces chipping, improves surface finish and extends tool life.
- Cutting Tool Design III：Circular flute design for better chip disposal, reduces chip packing, release stress and improving rigidity of the tool.
- Cutting Materials：Carbon steel, Chrome steel, Alloy steel, Stainless steel, Cast iron, Titanium alloy, Nickel-based alloy.
- Applications：Aerospace, Machinery, Mold ＆ Die, Automotive, Motorcycle.
Spec
| Inquiry | Model | Dia.(d) | Radius(R) | CL(L1) | OAL(L) | Shank(D) | Flutes(F) | Coating |
|---|---|---|---|---|---|---|---|---|
| | METVC4030002A | 3 | 0.2R | 8 | 50 | 6 | 4 | G1 |
| | METVC4030005A | 3 | 0.5R | 8 | 50 | 6 | 4 | G1 |
| | METVC4040002A | 4 | 0.2R | 10 | 50 | 6 | 4 | G1 |
| | METVC4040005A | 4 | 0.5R | 10 | 50 | 6 | 4 | G1 |
| | METVC4040010A | 4 | 1R | 10 | 50 | 6 | 4 | G1 |
| | METVC4050002A | 5 | 0.2R | 13 | 50 | 6 | 4 | G1 |
| | METVC4050005A | 5 | 0.5R | 13 | 50 | 6 | 4 | G1 |
| | METVC4050010A | 5 | 1R | 13 | 50 | 6 | 4 | G1 |
| | METVC4050015A | 5 | 1.5R | 13 | 50 | 6 | 4 | G1 |
| | METVC4060003A | 6 | 0.3R | 15 | 50 | 6 | 4 | G1 |
| | METVC4060005A | 6 | 0.5R | 15 | 50 | 6 | 4 | G1 |
| | METVC4060010A | 6 | 1R | 15 | 50 | 6 | 4 | G1 |
| | METVC4080003A | 8 | 0.3R | 20 | 60 | 8 | 4 | G1 |
| | METVC4080005A | 8 | 0.5R | 20 | 60 | 8 | 4 | G1 |
| | METVC4080010A | 8 | 1R | 20 | 60 | 8 | 4 | G1 |
| | METVC4080015A | 8 | 1R | 20 | 60 | 8 | 4 | G1 |
| | METVC4080020A | 8 | 2R | 20 | 60 | 8 | 4 | G1 |
| | METVC4100003A | 10 | 0.3R | 25 | 75 | 10 | 4 | G1 |
| | METVC4100005A | 10 | 0.5R | 25 | 75 | 10 | 4 | G1 |
| | METVC4100010A | 10 | 1R | 25 | 75 | 10 | 4 | G1 |
| | METVC4100015A | 10 | 1.5R | 25 | 75 | 10 | 4 | G1 |
| | METVC4100020A | 10 | 2R | 25 | 75 | 10 | 4 | G1 |
| | METVC4100030A | 10 | 3R | 25 | 75 | 10 | 4 | G1 |
| | METVC4120005A | 12 | 0.5R | 30 | 75 | 12 | 4 | G1 |
| | METVC4120010A | 12 | 1R | 30 | 75 | 12 | 4 | G1 |
| | METVC4120015A | 12 | 1.5R | 30 | 75 | 12 | 4 | G1 |
| | METVC4120020A | 12 | 2R | 30 | 75 | 12 | 4 | G1 |
| | METVC4120030A | 12 | 3R | 30 | 75 | 12 | 4 | G1 |
