CEC CARBIDE CONVEX END MILLS
PRODUCT FEATURES：
- Cutting Tool Design I：The cutting edge is precision-ground to ensure rigidity and accuracy, effectively reducing machining errors and achieving greater precision in keyway processing.
- Cutting Materials：Carbon steel, Chrome steel, Alloy steel, Stainless steel, Cast iron, Aluminum alloy, Copper alloy.
- Equipment：CNC Vertical Machining Center, Multi-Tasking Machine.
- Applications：Aerospace, Machinery, Mold ＆ Die, Automotive, Motorcycle, Mobile Phones, Display Panels.
Spec
| Inquiry | Model | Dia.(d) | Radius(R) | CL(L1) | Neck(Nd) | Neck(NL) | OAL(L) | Shank(D) | Flutes(F) | Coating |
|---|---|---|---|---|---|---|---|---|---|---|
| | CEC040006004A | 4 | 0.3R | 0.6 | 2 | 3.5 | 50 | 6 | 4 | TIALN |
| | CEC040010004A | 4 | 0.5R | 1 | 2 | 3.5 | 50 | 6 | 4 | TIALN |
| | CEC040020004A | 4 | 1R | 2 | 2 | 3.5 | 50 | 6 | 4 | TIALN |
| | CEC050006004A | 5 | 0.3R | 0.6 | 2.2 | 3.5 | 50 | 6 | 4 | TIALN |
| | CEC050010004A | 5 | 0.5R | 1 | 2.2 | 3.5 | 50 | 6 | 4 | TIALN |
| | CEC050020004A | 5 | 1R | 2 | 2.2 | 3.5 | 50 | 6 | 4 | TIALN |
| | CEC060006004A | 6 | 0.3R | 0.6 | 2.7 | 4 | 50 | 6 | 4 | TIALN |
| | CEC060010004A | 6 | 0.5R | 1 | 2.7 | 4 | 50 | 6 | 4 | TIALN |
| | CEC060020004A | 6 | 1R | 2 | 2.7 | 4 | 50 | 6 | 4 | TIALN |
| | CEC080006006A | 8 | 0.3R | 0.6 | 3.6 | 5 | 60 | 8 | 6 | TIALN |
| | CEC080010006A | 8 | 0.5R | 1 | 3.6 | 5 | 60 | 8 | 6 | TIALN |
| | CEC080020006A | 8 | 1R | 2 | 3.6 | 5 | 60 | 8 | 6 | TIALN |
| | CEC100006006A | 10 | 0.3R | 0.6 | 4.5 | 6 | 75 | 10 | 6 | TIALN |
| | CEC100010006A | 10 | 0.5R | 1 | 4.5 | 6 | 75 | 10 | 6 | TIALN |
| | CEC100020006A | 10 | 1R | 2 | 4.5 | 6 | 75 | 10 | 6 | TIALN |
| | CEC100030006A | 10 | 1.5R | 3 | 4.5 | 6 | 75 | 10 | 6 | TIALN |
| | CEC100040006A | 10 | 2R | 4 | 4.5 | 6 | 75 | 10 | 6 | TIALN |
| | CEC120006006A | 12 | 0.3R | 0.6 | 5.5 | 6 | 75 | 12 | 6 | TIALN |
| | CEC120010006A | 12 | 0.3R | 0.6 | 5.5 | 6 | 75 | 12 | 6 | TIALN |
| | CEC120020006A | 12 | 1R | 2 | 5.5 | 6 | 75 | 12 | 6 | TIALN |
| | CEC120030006A | 12 | 1.5R | 3 | 5.5 | 6 | 75 | 12 | 6 | TIALN |
| | CEC120040006A | 12 | 2R | 4 | 5.5 | 6 | 75 | 12 | 6 | TIALN |
| | CEC040006004 | 4 | 0.3R | 0.6 | 2 | 3.5 | 50 | 6 | 4 | — |
| | CEC040010004 | 4 | 0.5R | 1 | 2 | 3.5 | 50 | 6 | 4 | — |
| | CEC040020004 | 4 | 1R | 2 | 2 | 3.5 | 50 | 6 | 4 | — |
| | CEC050006004 | 5 | 0.3R | 0.6 | 2.2 | 3.5 | 50 | 6 | 4 | — |
| | CEC050010004 | 5 | 0.5R | 1 | 2.2 | 3.5 | 50 | 6 | 4 | — |
| | CEC050020004 | 5 | 1R | 2 | 2.2 | 3.5 | 50 | 6 | 4 | — |
| | CEC060006004 | 6 | 0.3R | 0.6 | 2.7 | 4 | 50 | 6 | 4 | — |
| | CEC060010004 | 6 | 0.5R | 1 | 2.7 | 4 | 50 | 6 | 4 | — |
| | CEC060020004 | 6 | 1R | 2 | 2.7 | 4 | 50 | 6 | 4 | — |
| | CEC080006006 | 8 | 0.3R | 0.6 | 3.6 | 5 | 60 | 8 | 6 | — |
| | CEC080010006 | 8 | 0.5R | 1 | 3.6 | 5 | 60 | 8 | 6 | — |
| | CEC080020006 | 8 | 1R | 2 | 3.6 | 5 | 60 | 8 | 6 | — |
| | CEC100006006 | 10 | 0.3R | 0.6 | 4.5 | 6 | 75 | 10 | 6 | — |
| | CEC100010006 | 10 | 0.5R | 1 | 4.5 | 6 | 75 | 10 | 6 | — |
| | CEC100020006 | 10 | 1R | 2 | 4.5 | 6 | 75 | 10 | 6 | — |
| | CEC100030006 | 10 | 1.5R | 3 | 4.5 | 6 | 75 | 10 | 6 | — |
| | CEC100040006 | 10 | 2R | 4 | 4.5 | 6 | 75 | 10 | 6 | — |
| | CEC120006006 | 12 | 0.3R | 0.6 | 5.5 | 6 | 75 | 12 | 6 | — |
| | CEC120010006 | 12 | 0.5R | 1 | 5.5 | 6 | 75 | 12 | 6 | — |
| | CEC120020006 | 12 | 1R | 2 | 5.5 | 6 | 75 | 12 | 6 | — |
| | CEC120030006 | 12 | 1.5R | 3 | 5.5 | 6 | 75 | 12 | 6 | — |
| | CEC120040006 | 12 | 2R | 4 | 5.5 | 6 | 75 | 12 | 6 | — |
