CEK CARBIDE T-SLOT KEYSEAT END MILLS- Flat Flute
PRODUCT FEATURES：
- Cutting Tool Design I：The cutting edge is precision-ground to ensure rigidity and accuracy, effectively reducing machining errors and achieving greater precision in keyway processing.
- Cutting Materials：Carbon steel, Chrome steel, Alloy steel, Stainless steel, Cast iron, Aluminum alloy, Copper alloy.
- Equipment：CNC Vertical Machining Center, Multi-Tasking Machine.
- Applications：Aerospace, Machinery, Mold ＆ Die, Automotive, Motorcycle, Mobile Phones, Display Panels.
Spec
| Inquiry | Model | Dia.(d) | CL(L1) | Neck(Nd) | Neck(NL) | OAL(L) | Shank(D) | Flutes(F) | Coating |
|---|---|---|---|---|---|---|---|---|---|
| | CEK040005004A | 4 | 0.5 | 2.5 | 3.5 | 50 | 4 | 4 | TIALN |
| | CEK040006004A | 4 | 0.6 | 2.5 | 3.5 | 50 | 4 | 4 | TIALN |
| | CEK040007004A | 4 | 0.7 | 2.5 | 3.5 | 50 | 4 | 4 | TIALN |
| | CEK040008004A | 4 | 0.8 | 2.5 | 3.5 | 50 | 4 | 4 | TIALN |
| | CEK040009004A | 4 | 0.9 | 2.5 | 3.5 | 50 | 4 | 4 | TIALN |
| | CEK040010004A | 4 | 1 | 2.5 | 3.5 | 50 | 4 | 4 | TIALN |
| | CEK040015004A | 4 | 1.5 | 2.5 | 3.5 | 50 | 4 | 4 | TIALN |
| | CEK040020004A | 4 | 2 | 2.5 | 3.5 | 50 | 4 | 4 | TIALN |
| | CEK050005004A | 5 | 0.5 | 2.5 | 4 | 50 | 6 | 4 | TIALN |
| | CEK050006004A | 5 | 0.6 | 2.5 | 4 | 50 | 6 | 4 | TIALN |
| | CEK050007004A | 5 | 0.7 | 2.5 | 4 | 50 | 6 | 4 | TIALN |
| | CEK050008004A | 5 | 0.8 | 2.5 | 4 | 50 | 6 | 4 | TIALN |
| | CEK050009004A | 5 | 0.9 | 2.5 | 4 | 50 | 6 | 4 | TIALN |
| | CEK050010004A | 5 | 1 | 2.5 | 4 | 50 | 6 | 4 | TIALN |
| | CEK050015004A | 5 | 1.5 | 2.5 | 4 | 502 | 6 | 4 | TIALN |
| | CEK050020004A | 5 | 2 | 2.5 | 4 | 50 | 6 | 4 | TIALN |
| | CEK060005006A | 5 | 2 | 2.5 | 4 | 50 | 6 | 4 | TIALN |
| | CEK060006006A | 6 | 0.5 | 3 | 4 | 50 | 6 | 6 | TIALN |
| | CEK060007006A | 6 | 0.7 | 3 | 4 | 50 | 6 | 4 | TIALN |
| | CEK060008006A | 6 | 0.8 | 3 | 4 | 50 | 6 | 6 | TIALN |
| | CEK060009006A | 6 | 0.9 | 3 | 4 | 50 | 6 | 6 | TIALN |
| | CEK060010006A | 6 | 1 | 3 | 4 | 50 | 6 | 6 | TIALN |
| | CEK060015006A | 6 | 1.5 | 3 | 4 | 50 | 6 | 6 | TIALN |
| | CEK060020006A | 6 | 2 | 3 | 4 | 50 | 6 | 6 | TIALN |
| | CEK080010006A | 8 | 1 | 4 | 4 | 60 | 8 | 6 | TIALN |
| | CEK080015006A | 8 | 1.5 | 4 | 4 | 60 | 8 | 6 | TIALN |
| | CEK080020006A | 8 | 2 | 4 | 4 | 60 | 8 | 6 | TIALN |
| | CEK100010006A | 10 | 1 | 5 | 6 | 75 | 10 | 6 | TIALN |
| | CEK100015006A | 10 | 1.5 | 5 | 6 | 75 | 10 | 6 | TIALN |
| | CEK100020006A | 10 | 2 | 5 | 6 | 75 | 10 | 6 | TIALN |
| | CEK120010006A | 12 | 1 | 6 | 7 | 75 | 12 | 6 | TIALN |
| | CEK120015006A | 12 | 1.5 | 6 | 7 | 75 | 12 | 6 | TIALN |
| | CEK120020006A | 12 | 2 | 6 | 7 | 75 | 12 | 6 | TIALN |
| | CEK040005004 | 4 | 0.5 | 2.5 | 3.5 | 50 | 4 | 4 | — |
| | CEK040006004 | 4 | 0.6 | 2.5 | 3.5 | 50 | 4 | 4 | — |
| | CEK040007004 | 4 | 0.7 | 2.5 | 3.5 | 50 | 4 | 4 | — |
| | CEK040008004 | 4 | 0.8 | 2.5 | 3.5 | 50 | 4 | 4 | — |
| | CEK040009004 | 4 | 0.9 | 2.5 | 3.5 | 50 | 4 | 4 | — |
| | CEK040010004 | 4 | 1 | 2.5 | 3.5 | 50 | 4 | 4 | — |
| | CEK040015004 | 4 | 1.5 | 2.5 | 3.5 | 50 | 4 | 4 | — |
| | CEK040020004 | 4 | 2 | 2.5 | 3.5 | 50 | 4 | 4 | — |
| | CEK050005004 | 5 | 0.5 | 2.5 | 4 | 50 | 6 | 4 | — |
| | CEK050006004 | 5 | 0.6 | 2.5 | 4 | 50 | 6 | 4 | — |
| | CEK050007004 | 5 | 0.7 | 2.5 | 4 | 50 | 6 | 4 | — |
| | CEK050008004 | 5 | 0.8 | 2.5 | 4 | 50 | 6 | 4 | — |
| | CEK050009004 | 5 | 0.9 | 2.5 | 4 | 50 | 6 | 4 | — |
| | CEK050010004 | 5 | 1 | 2.5 | 4 | 50 | 6 | 4 | — |
| | CEK050015004 | 5 | 1.5 | 2.5 | 4 | 50 | 6 | 4 | — |
| | CEK050020004 | 5 | 2 | 2.5 | 4 | 50 | 6 | 4 | — |
| | CEK060005006 | 6 | 0.5 | 3 | 4 | 50 | 6 | 6 | — |
| | CEK060006006 | 6 | 0.6 | 3 | 4 | 50 | 6 | 6 | — |
| | CEK060007006 | 6 | 0.7 | 3 | 4 | 50 | 6 | 6 | — |
| | CEK060008006 | 6 | 0.8 | 3 | 4 | 50 | 6 | 6 | — |
| | CEK060009006 | 6 | 0.9 | 3 | 4 | 50 | 6 | 6 | — |
| | CEK060010006 | 6 | 1 | 3 | 4 | 50 | 6 | 6 | — |
| | CEK060015006 | 6 | 1.5 | 3 | 4 | 50 | 6 | 6 | — |
| | CEK060020006 | 6 | 2 | 3 | 4 | 50 | 6 | 6 | — |
| | CEK080010006 | 8 | 1 | 4 | 4 | 60 | 8 | 6 | — |
| | CEK080015006 | 8 | 1.5 | 4 | 4 | 60 | 8 | 6 | — |
| | CEK080020006 | 8 | 2 | 4 | 4 | 60 | 8 | 6 | — |
| | CEK100010006 | 10 | 1 | 5 | 6 | 75 | 10 | 6 | — |
| | CEK100015006 | 10 | 1.5 | 5 | 6 | 75 | 10 | 6 | — |
| | CEK100020006 | 10 | 2 | 5 | 6 | 75 | 10 | 6 | — |
| | CEK120010006 | 12 | 1 | 6 | 7 | 75 | 12 | 6 | — |
| | CEK120015006 | 12 | 1.5 | 6 | 7 | 75 | 12 | 6 | — |
| | CEK120020006 | 12 | 2 | 6 | 7 | 75 | 12 | 6 | — |
