CECS CARBIDE DOVETAIL END MILLS- Flat Flute
PRODUCT FEATURES：
- Cutting Tool Design I：The cutting edge is precision-ground to ensure rigidity and accuracy, effectively reducing machining errors and achieving greater precision in keyway processing.
- Cutting Materials：Carbon steel, Chrome steel, Alloy steel, Stainless steel, Cast iron, Aluminum alloy, Copper alloy.
- Equipment：CNC Vertical Machining Center, Multi-Tasking Machine.
- Applications：Aerospace, Machinery, Mold ＆ Die, Automotive, Motorcycle, Mobile Phones, Display Panels.
Spec
| Inquiry | Model | Dia.(d) | δ˚ | CL(L1) | Neck(Nd) | Neck(NL) | OAL(L) | Shank(D) | Flutes(F) | Coating |
|---|---|---|---|---|---|---|---|---|---|---|
| | CECS03000800445A | 3 | 4.5° | 0.8 | 1.4 | 3 | 60 | 6 | 4 | TIALN |
| | CECS04001000445A | 4 | 45° | 1 | 2 | 3.5 | 60 | 6 | 4 | TIALN |
| | CECS05001200445A | 5 | 45° | 1.2 | 2.5 | 4 | 60 | 6 | 4 | TIALN |
| | CECS06001400445A | 6 | 45° | 1.4 | 3 | 4 | 60 | 6 | 4 | TIALN |
| | CECS08001900645A | 8 | 45° | 1.9 | 4 | 5 | 60 | 8 | 6 | TIALN |
| | CECS10002400645A | 10 | 45° | 2.4 | 5 | 6 | 75 | 10 | 6 | TIALN |
| | CECS12002900645A | 12 | 45° | 2.9 | 6 | 7 | 75 | 12 | 6 | TIALN |
| | CECS03001200460A | 3 | 60° | 1.2 | 1.5 | 3 | 60 | 6 | 4 | TIALN |
| | CECS04001600460A | 4 | 60° | 1.6 | 2 | 3.5 | 60 | 6 | 4 | TIALN |
| | CECS05002200460A | 5 | 60° | 2.2 | 2.3 | 4 | 60 | 6 | 4 | TIALN |
| | CECS06002700460A | 6 | 60° | 2.7 | 2.7 | 4 | 60 | 6 | 4 | TIALN |
| | CECS08003700660A | 8 | 60° | 3.7 | 3.6 | 5 | 60 | 8 | 6 | TIALN |
| | CECS10004600660A | 10 | 60° | 4.6 | 4.5 | 6 | 75 | 10 | 6 | TIALN |
| | CECS12005600660A | 12 | 60° | 5.6 | 5.4 | 7 | 75 | 12 | 6 | TIALN |
| | CECS03000800445 | 3 | 45° | 0.8 | 1.4 | 3 | 60 | 6 | 4 | — |
| | CECS04001000445 | 4 | 45° | 1 | 2 | 3.5 | 60 | 6 | 4 | — |
| | CECS05001200445 | 5 | 45° | 1.2 | 2.5 | 4 | 60 | 6 | 4 | — |
| | CECS06001400445 | 6 | 45° | 1.4 | 3 | 4 | 60 | 6 | 4 | — |
| | CECS08001900645 | 8 | 45° | 1.9 | 4 | 5 | 60 | 8 | 6 | — |
| | CECS10002400645 | 10 | 45° | 2.4 | 5 | 6 | 75 | 10 | 6 | — |
| | CECS12002900645 | 12 | 45° | 2.9 | 6 | 7 | 75 | 12 | 6 | — |
| | CECS03001200460 | 3 | 60° | 1.2 | 1.5 | 3 | 60 | 6 | 4 | — |
| | CECS04001600460 | 4 | 60° | 1.6 | 2 | 3.5 | 60 | 6 | 4 | — |
| | CECS05002200460 | 5 | 60° | 2.2 | 2.3 | 4 | 60 | 6 | 4 | — |
| | CECS06002700460 | 6 | 60° | 2.7 | 2.7 | 4 | 60 | 6 | 4 | — |
| | CECS08003700660 | 8 | 60° | 3.7 | 3.6 | 5 | 60 | 8 | 6 | — |
| | CECS10004600660 | 10 | 60° | 4.6 | 4.5 | 6 | 75 | 10 | 6 | — |
| | CECS12005600660 | 12 | 60° | 5.6 | 5.4 | 7 | 75 | 12 | 6 | — |
